PreSonus StudioLive 24 Digital Mixing Console/Recorder Features:

• 24-channel digital mixing console with built-in SD card recorder
• Record and play back up to 38 channels via USB, or up to 55 channels via AVB Ethernet
• Built-in SD card support for multitrack recording and virtual soundchecks
• Fully-recallable XMAX preamps with ultra-low noise floor
• 25 touch-sensitive motorized faders allow you to mix with precision
• 24 DCA groups help you manage complex productions with high channel counts
• Four internal effects buses
• Support for insert effects on up to four channels
• Fat Channel processing provides vintage EQ and compression options for each channel
• Better visual feedback than ever, with full-color touchscreen and channel scribble strips
• Advanced scene management helps you manage complex mixing tasks more efficiently
• 16 Flex Mixes can be used as Aux mixes, Subgroups, or Matrix mixes
• Bluetooth wireless streaming makes it easy to play music from a smartphone or tablet
• Software package includes UC Surface 2 touch-control software (Mac/PC/iOS), Capture recording software (Mac/PC), Studio One Artist DAW software (Mac/PC), QMix personal monitoring app (iOS/Android)
• Compatible with the Fat Channel Collection (sold separately)

Tech Specs

• Type:Digital Console/Recorder
• Channels:24 physical, 32 internal
• Inputs - Mic Preamps:12 x XLR (mic), 12 x XLR-1/4" combo (mic/line)
• Phantom Power:Switchable per channel
• Inputs - Line:4 x 1/4" (2 stereo aux in), 1 x Stereo RCA (tape in)
• Outputs - Main:2 x XLR (main out), 2 x 1/4" (monitor), 1 x XLR (mono sum)
• Outputs - Other:8 x XLR (mix out), 8 x 1/4" (mix out), 1 x Stereo RCA (tape out)
• Inputs - Digital:Bluetooth streaming
• Outputs - Digital:1 x XLR (AES)
• Busses/Groups:16 FlexMix Bus (subgroups, matrix mixes, aux mixes)
• Talkback:1 x XLR (with phantom power)
• Data I/O:1 x Ethercon (AVB Audio Network), 1 x RJ45 (network control)
• USB:1 x Type B
• Computer Connectivity:USB (38 x 38), Ethernet (AVB 55 x 55)
• Bluetooth:v4.1
• Headphones:1 x 1/4"
• Faders:25 x touch-sensitive, motorized
• EQ Bands:Parametric EQ per channel, Graphic, Vintage EQ's
• Effects:Reverb, Delay, Vintage modeling, Studio Magic plug-in suite
• Signal Processing:Fat Channel processing (filter, gate, compressor)
• Transport Controls:Yes
• DAW Control:Yes (Studio One)
• Screen:7" touchscreen
• Storage:SD/SDHC card slot (up to 32GB)
• Software:Studio One Artist (Windows,Mac), QMix-UC control software (iOS, Android), UC Surface touch (Windows, Mac, iPad)
• Height:7"
• Depth:23"
• Width:25.6"
• Weight:30 lbs.
• Manufacturer Part Number:SLMAD24
