General Information
| Number of light sources |
3 pcs
|
| Light source color |
840 neutral white
|
| Light source replaceable |
No
|
| Number of gear units |
2 units
|
| Driver/power unit/transformer |
Power supply unit
|
| Driver included |
Yes
|
| Optic type |
Beam angle 60 to 120°
|
| Optical cover/lens type |
Variable linear-lens array in polycarbonate cover
|
| Luminaire light beam spread |
110° x 110°
|
| Protection class IEC |
Safety class I
|
| Glow-wire test |
Temperature 650 °C, duration 30 s
|
| CE mark |
-
|
| ENEC mark |
-
|
| UL mark |
-
|
| Constant light output |
Yes
|
| Spare parts available |
Yes
|
Operating and Electrical
| Input Voltage |
220-240 V
|
| Power Factor (Nom) |
0.9
|
Controls and Dimming
| Dimmable |
No
|
Mechanical and Housing
| Housing Material |
Steel
|
| Reflector material |
Steel
|
Approval and Application
| Ingress protection code |
IP20 [ Finger-protected]
|
| Mech. impact protection code |
IK02 [ 0.2 J standard]
|
Initial Performance (IEC Compliant)
| Luminous flux tolerance |
+/-10%
|
| Init. Corr. Color Temperature |
4000 K
|
| Init. Color Rendering Index |
80
|
| Initial input power |
51.5 W
|
| Power consumption tolerance |
+/-10%
|
Over Time Performance (IEC Compliant)
| Median useful life L70B50 |
25000 h
|
Application Conditions
| Ambient temperature range |
-20 to +40 °C
|
| Average ambient temperature |
25 °C
|
Product Data
| Full product code |
911401540321
|
| Order product name |
RC098V LED44S/840 W60L120 GM
|
| Order code |
911401540321
|
| Numerator - Quantity Per Pack |
1
|
